Low Pressure Switch
The Low Pressure Switch are used in different types of water tanks and pressure tank systems which closed or open with float valves. When the water pressure in the lines drops lower than the set pressure. Then a pressure switch cuts off the power supply and the pump will automatically turn off. This switch increases the life of your pump, this is compatible with all the types of Water System. Made up of anti rust and Anti- Corrosive material which is very long lasting. It is a very high efficient switch which will effectively switch off the pump when pressure lowers than the optimum set pressure.
Low pressure Switch kp1 Main Features
- Compact and robust design:Built for harsh industrial environments.
- High pressure capability:Handles pressures up to 17 bar (245 psi).
- Adjustable pressure range:Allows for precise control over various pressure settings.
- Durable internal components:Ensures long-lasting performance and reliability.
- Variety of electrical connections:It provides flexibility for different wiring configurations.
- Multiple contact functions:It offers options for various control applications.
- Wide range of approvals:It meets international protection and quality standards.
Considerable Factors:
- As with the KP36, ensure the KP35’s pressure range and other specifications match your application’s requirements.
- While both switches share similar features and design, their pressure ranges are distinct. Choose the appropriate switch based on your pressure control needs.
Applications:
- Vacuum systems
- Refrigeration systems
- Air compressors
- Hydraulic systems
- Water treatment systems
- HVAC systems
RO low Pressure Switch Price- INR -1699/-
For more information visit on our official Website https://waterpurifier.work/
Water Low Pressure Switch Specifications
Brand | Danfoss | |
Enclosure rating IP | IP30 | |
Enclosure rating Nema (~) | 1 | |
Max. test pressure [bar] Pe | 22 Bar | |
Max. test pressure [psig] | 319 psig | |
Max. Working Pressure [bar] | 17 bar | |
Max. Working Pressure [psig] | 245 psig | |
Packing format | single | |
Pressure connection size | 1/4 | |
|
ISO 228-1 | |
Type | Solid | |
Country of Origin | Denmark | |
Pressure range category | Low pressure | |
Enclosure rating IP | IP30 | |
Micron Rating | 0.001 | |
Colour | White | |
Product family name | KP35 | |
Shelf Life | 12 Months | |
Qty. | 1 |
